2-215309-0
Manufacturer:
TE Connectivity
Mfr.Part #:
2-215309-0
Datasheet:
Description:
Headers and Wire Housings Through Hole Receptacle Number of Positions:20 Pitch:2.54 mm
| Parameter | Value |
|---|---|
| Length | 50.8 mm |
| Termination | Solder |
| Max Operating Temperature | 105 °C |
| Min Operating Temperature | -65 °C |
| Height | 8.5 mm |
| Packaging | Bulk |
| Depth | 5.06 mm |
| Radiation Hardening | No |
| RoHS | Compliant |
| REACH SVHC | Unknown |
| Contact Plating | Tin, Gold |
| Lead Length | 3.1 mm |
| Contact Material(Contact Finish) | Bronze |
| Pitch | 2.54 mm |
| Current Rating | 3 A |
| Flammability Rating | UL94 V-0 |
| Orientation | Vertical |
| Lifecycle Status | Production (Last Updated: 1 week ago) |
| Color | Green |
| Gender | Socket (Female) |
| Number of Contacts | 20 |
| Connector Type | Receptacle |
| Number of Positions | 20 |
| Number of Rows | 2 |
| Row Spacing | 2.54 mm |
| Housing Material | Polyester |
| Contact Style | Socket |
| Contact Resistance | 12 mΩ |
| Contact Current Rating | 3 A |
| Housing Color | Green |
| Plating | Gold |
| PCB Mounting Orientation | Vertical |
| PCB Thickness | 1.6 mm |
| Tail Length | 3.1 mm |
| Stackable | Yes |
| Contact Shape | Square |
| Manufacturer Lifecycle Status | ACTIVE (Last Updated: 1 week ago) |
| Sealable | No |
| Contact Finish Thickness - Mating | 762 nm |
| Termination Post Length | 3.1 mm |
| PCB Mount Retention | With |
Stock: 473
Distributors
pcbx
pcbxUnit Price$3.89848
Ext.Price$3.89848
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $3.89848 | $3.89848 |
| 10 | $3.45038 | $34.50380 |
| 25 | $3.05381 | $76.34525 |
| 50 | $3.04783 | $152.39150 |
| 100 | $2.86641 | $286.64100 |
| 300 | $2.69579 | $808.73700 |
| 500 | $2.53533 | $1267.66500 |
| 1000 | $2.38440 | $2384.40000 |
